IP68 LED Marine Lanterns Boat Running Light support AIS functions

Place of Origin:

Chengdu

Brand Name:

Dexon

Certification:

CE, ISO9001, IALA

Model Number:

DX-ML160

Request A Quote

IP68 LED Marine Lanterns Boat Running Light support AIS functions

Product Details

Color:

Red/Green/Yellow/White/Blue/Yellow-Blue

Light Source:

LED

Lens Material:

Acrylic

Operating Temperature:

-35°C To +65°C

Waterproof Rating:

IP68

Lens Size:

155mm

Payment & Shipping Terms

Minimum Order Quantity

Price

USD 680～1000

Packaging Details

cartons/pallets

Delivery Time

3～10 days

Payment Terms

D/A,D/P,T/T,Western Union,MoneyGram,L/C

Supply Ability

10000/month

12V Marine 11nm IP68 LED Navigation Lights For Boat / Fixed Lighthouse / Floating Buoys

Get Best Price

IP68 DC Powered LED Navigation Lantern AIS AtoN Light For Fixed Beacons

Get Best Price

Video

20NM Range AIS AtoN LED Navigation Lanterns IP68 SOTDMA Mode Screw Mounting

Get Best Price

IP68 6.6W LED Marine Lanterns LED Boat Running Light support external AIS Option

Get Best Price

Contact Now

Product Description

This upgraded LED marine lantern features a high-strength composite housing used in high-speed rail systems, offering superior durability in harsh marine environments. With a visible range of over 10 nautical miles and five selectable light colors, it ensures reliable navigation marking across varied conditions. The built-in SOTDMA AIS mode (with FATDMA and RATDMA support) guarantees seamless global AtoN compatibility, making it ideal for offshore, autonomous deployment.

Core advantages

^{With long distance 10NM+ visible range}
^{SOTDMA default AIS communication, FATDMA and RATDMA adjustible.}
^{Five light colors selectable}
^{High-strength composite body (same grade as bullet train casings)}
^{464 cd brightness / 6.6W power}
^{Smart BMS + 8–32V wide input}
^{IP68-rated, long-term field durability}

Technical specification

Category	Specification	Details
Main features	Operating Voltage	DC 8V—32V, intelligent compatibility with DC 12V and 24V
	Flash Mode	256 adjustable options Brightness: Adjustable by percentage
	Light Color	Red/Green/Yellow/White/Blue/Yellow-Blue
	Illumination Distance	5—11nm @ 0.74T
	Daylight Threshold	Digital light sensor, adjustable threshold
	Waterproof Rating	IP68
	Operating Temperature	-35°C to +65°C
	Emission Angle	Fixed Light ≥2.5°
	Horizontal Max Luminous Intensity	White: 2800cd/33.6W ｜ Red: 1955.9cd/19.8W Yellow: 1186cd/22.9W ｜ Blue: 663cd/33.6W Green: 1587cd/33.9W
	LED Lifespan	>100,000 hours
Light features	Lens Material	Optical Acrylic
	Lens Size	155mm
	Shell Material	Composite SMC (Fiberglass)
	Charging Current	≤10A
	Synchronous Flash	Synchronous flashing function
	Number of Layers	One or two layers controllable
	Parameter Setting	RS232, Button
	Installation Size	Conforms to domestic and international standards
	Weight	≤2.6KG
	Product Size	240240267mm

Drawings

IP68 LED Marine Lanterns Boat Running Light support AIS functions 1

Application

Buoys
Beacons
Harbor Entrances
Offshore Platforms
Floating AtoN Installations
Fixed AtoN Installations
Marinas
Docks & Piers
Channel Markers

FAQ

1, What kind of AIS support is included?

Compatible with SOTDMA, FATDMA, and RATDMA protocols.

2, How strong is the AIS signal?

Equipped with a high-gain VHF antenna for 360° coverage.

3, Is it suitable for unmanned deployments?

Yes. Optimized for autonomous AtoN with intelligent BMS (8–32V DC).

4, What’s the size and delivery time?

Weight 2.6 kg, product size is 240×240×267 mm. Ships in 3–10 days.

5, Is it usable for global AIS coverage?

Yes. Compact and protocol-compatible for worldwide marine systems.
