Custom Solar Marine Lanterns Solar Powered Boat Navigation Lights With AIS
Product Summary
Designed for smart marine operations, and it supports AIS message types 6, 8, 21, and optionally 7, 12, 20, and 25- makes it highly adaptable to modern port and VTS systems. It comes with AIS-ready options, both built-in and external, and supports SOTDMA, FATDMA and RATDMA protocols. Fast and ...
Product Custom Attributes
Material:
Acrylic Lens,ABS+PC Base
Flash Mode:
256 Types(selectable)
Light Color:
Red/Green/Yellow/White/Blue
Visible Range:
5–8 Nautical Miles
Ingress Protection:
IP68
Operating Temperature:
-35°C To +60°C
Highlight:
Custom Solar Marine Lanterns
,Solar Boat Navigation Lights With AIS
Basic Properties
Place of Origin:
Chengdu
Brand Name:
Dexon
Certification:
CE, ISO9001, IALA
Model Number:
SC160FL
Trading Properties
Minimum Order Quantity:
1
Price:
2500-3000
Packaging Details:
cartons/pallets
Delivery Time:
3～10 days
Payment Terms:
D/A,D/P,T/T,Western Union,MoneyGram,L/C
Supply Ability:
10000/month
Product Description
Designed for smart marine operations, and it supports AIS message types 6, 8, 21, and optionally 7, 12, 20, and 25- makes it highly adaptable to modern port and VTS systems.
It comes with AIS-ready options, both built-in and external, and supports SOTDMA, FATDMA and RATDMA protocols.
Fast and flexible setup is made possible through RS232 interface or simple button configuration.
Perfect for AIS AtoN deployments across ports, canals, and critical navigation zones.
Core advantages
- Supports AIS messages 6, 8, 21, and more for seamless integration with modern VTS and port systems.
- Compatible with SOTDMA, FATDMA, and RATDMA to ensure flexible AIS AtoN deployment.
- Offers built-in or external AIS options to suit various installation requirements.
- Quick configuration via RS232 or one-button setup simplifies on-site deployment.
- Ideal for ports, canals, and critical navigation zones requiring reliable signal marking.
Product details
Technical specification
| Category | Specification | Details |
|---|---|---|
|
Main features
|
Material
|
Acrylic lens,ABS+PC base
|
|
Flash Mode
|
256 types(selectable)
|
|
|
Light Color
|
Red/Green/Yellow/White/Blue
|
|
|
Visible Range
|
5–8 nautical miles
|
|
|
Daylight Threshold
|
Digital photosensitive, adjustable threshold
|
|
|
Ingress Protection
|
IP68
|
|
|
Operating Temperature
|
-35°C to +60°C
|
|
|
Emission Angle
|
Floating Light ≥8°, Fixed Light ≥2.5°
|
|
|
Working Voltage
|
DC 10.5V – 14.4V
|
|
|
Parameter Loading
|
RS232 and onboard button
|
|
|
Solar Panel & Battery
|
Solar Panel
|
4*7W, high-efficiency mono-solar panel
|
|
Charging Current
|
Typical 400mA
|
|
|
Battery
|
LiFePO4 battery, capacity 640Wh
|
|
|
Continuous Operation
|
≥25 days (without sun)
|
|
|
AIS AtoN
|
Communication
|
Default Mode3-SOTDMA ,
(FATDMA / RATDMA / SOTDMA, adjustable) |
|
Operating Frequency
|
161.975MHz,162.025MHz (±0.5kHz)
|
|
|
Modulation Mode
|
GMSK / FSK
|
|
|
Transmission Power
|
1W / 2W / 5W / 6W / 12.5W (configurable)
|
|
|
Average Power Consumption
|
≤ 1W (continuous working mode),Low power mode ≤0.7W
|
|
|
Message Format
|
Supports standard AIS Message 21, 6; multiple formats selectable
|
|
|
W/D/K
|
Net Weight
|
9.3 kg
|
|
Dimensions
|
Floating Light: 240mm × 240mm × 489mm
|
|
|
Packaging Dimensions
|
277mm × 281mm × 537mm
|
|
|
Installation
|
Meets domestic and international installation standards
|
Drawings
Application
- Floating AtoN Installations
- Buoys
- Beacons
- Harbor Entrances
- Offshore Platforms
FAQ
1, Which AIS messages are supported?
Compatible with Msg 6, 8, 21 and more, and is prepared for VTS/port integration.
2, What AIS deployment modes are available?
Fully compatible with SOTDMA, FATDMA and RATDMA.
3, Does the configuration process complex?
No, the light can be set up quickly via RS232 or one-button configuration.
4, Can I choose internal or external AIS?
Yes. Both built-in and external AIS options available.
5, What are the size and delivery specifications?
Light weighs 9.3 kg, delivery dimensions: 277 x 281 x 537 mm. Ships in 3–10 days.
