Name: 20 NM solar-powered marine navigation lantern beacon light for buoys with AIS AtoN support
Brand: Chengdu Dixin Technology Co., Ltd.
SKU: AIS60FX
Price: 2,750.00 USD
Availability: InStock

Home > products > Solar Marine Lanterns >

20 NM solar-powered marine navigation lantern beacon light for buoys with AIS AtoN support

Solar Marine Lanterns OEM

Solar Navigation Light With AIS AtoN

Place of Origin:

Chengdu

Brand Name:

Dexon

Certification:

CE, ISO9001, IALA

Model Number:

AIS60FX

Request A Quote

20 NM solar-powered marine navigation lantern beacon light for buoys with AIS AtoN support

Product Details

Visible Range:

5–8 Nautical Miles

Solar Panel:

4*7W, High-efficiency Mono-solar Panel

Flash Mode:

256 Types(selectable)

Material:

Acrylic Lens,ABS+PC Base

Working Voltage:

DC 10.5V – 14.4V

Waterproof:

IP68

Battery Capacity:

LifePO4 Battery ≥486Wh @4000times DOD

Lifespan:

15 Years

Color:

White, Red, Yellow, Green, Blue

Certifications:

CE, RoHS, ISO,IEC, IALA

Operating Temperature:

-35°C To 60°C

Light Angel:

Buoy Light ≥8°, Fixed Light ≥2.5°

Service:

Logo OEM , ODM, Customized Detailed Requiements

Highlight:

Solar Marine Lanterns OEM

Solar Navigation Light With AIS AtoN

Payment & Shipping Terms

Minimum Order Quantity

Price

2500-3000

Packaging Details

cartons/pallets

Delivery Time

3～10 days

Payment Terms

D/A,D/P,T/T,Western Union,MoneyGram,L/C

Supply Ability

10000/month

20 NM solar-powered marine navigation lantern beacon light for buoys with AIS AtoN support

Get Best Price

Customizable Marine Electronic Fence Smart Warning System Real Time Tracking

Get Best Price

Precision Ultrasonic Wind Speed And Direction Sensor Lightweight Robust Design

Get Best Price

Solar Powered Marine Navigation Lights For Remote Buoys And Harbor Entrances

Get Best Price

Contact Now

Product Description

20NM｜Solar-Powered Marine Navigation Lantern

For Buoys｜With AIS AtoN Support

Discover high-performance, low-power navigation with our advanced marine AIS lantern, engineered for offshore environments, buoy systems, and coastal installations. With ultra-low energy consumption (average ≤1W) and adjustable transmission power from 1W to 12.5W, it ensures reliable operation without compromising efficiency. A 3-meter high-gain 316 stainless steel antenna provides robust and stable VHF signal coverage, even under harsh conditions.

The lantern supports triple AIS communication modes—FATDMA, RATDMA, and SOTDMA—making it ideal for flexible deployments across different AtoN systems. Visibility is optimized through 256 selectable flash patterns and five adjustable light colors (red, green, white, yellow, blue), ensuring clarity and compliance in varied marine scenarios. With a visibility range of 5–8 nautical miles and a 3-year free replacement warranty, this solution combines performance, adaptability, and peace of mind.

Built for modern navigation needs, it's the perfect blend of efficiency, intelligence, and durability.

Core advantages

Low power, High efficiency: 1~12.5W optional transmission power and an average consumption ≤ 1 W
High-gain VHF band antenna:3-metre 316 stainless steel antenna
Triple AIS modes: Default Mode3-SOTDMA, (FATDMA, RATDMA and SOTDMA) for flexible deployment
Warranty: 3-year free replacement
256 flashing modes and 5 colors red/green/white/yellow/blue) adjustible
Visibility range of 5–8 nautical miles

Product details

Technical specification

Category	Specification	Details
Main features	Material	Acrylic lens,ABS+PC base
	Flash Mode	256 types(selectable)
	Light Colore	Red/Green/Yellow/White/Blue
	Visible Range	5–8 nautical miles
	Daylight Threshold	Digital photosensitive, adjustable threshold
	Ingress Protection	IP68
	Operating Temperature	-35°C to +60°C
	Emission Angle	Floating Light ≥8°, Fixed Light ≥2.5°
	Working Voltage	DC 10.5V – 14.4V
	Parameter Loading	RS232 and onboard button
Solar Panel & Battery	Solar Panel	4*7W, high-efficiency mono-solar panel
	Charging Current	Typical 400mA
	Battery	LiFePO4 battery, capacity 640Wh
	Continuous Operation	≥25 days (without sun)
AIS AtoN	Communication	Default Mode3-SOTDMA , (FATDMA / RATDMA / SOTDMA, adjustable)
	Operating Frequency	161.975MHz,162.025MHz (±0.5kHz)
	Modulation Mode	GMSK / FSK
	Transmission Power	1W / 2W / 5W / 6W / 12.5W (configurable)
	Average Power Consumption	≤ 1W (continuous working mode) Low power mode ≤0.7W
	Message Format	Supports standard AIS Message 21, 6; multiple formats selectable
W/D/K	Net Weight	9.3 kg
	Dimensions	Floating Light: 240mm × 240mm × 489mm Fixed Light: 240mm × 240mm × 455mm
	Packaging Dimensions	277mm × 281mm × 537mm
	Installation	Meets domestic and international installation standards

Drawings

Two Models

Application

Buoys
Beacons
Harbor Entrances
Offshore Platforms
Floating & Fixed AtoN Installations

FAQ

1, Only available in a solar-powered version?

we also offer DC-powered version.

2, What optional features are available?

Optional features include Satellite Communication,329 IALA,AIS,GPS Sync,Bluetooth.

3, What kind of installations is it suitable for?

It’s suitable for fixed beacons, buoys, harbor entrances, offshore platforms, and more.
