Fixed AIS Base Station IP68 Rated Long Range Marine Communication For Coastal Inland Waterways
Product Summary
IP68-rated, long-range marine communication for coastal and inland waterways, provided by the fixed AIS base station Designed for seamless integration with Dexonmarine’s AIS AtoN systems, the DX082FA forms a fully compatible solution that meets IALA and IMO standards. It supports multiple AIS ...
Product Custom Attributes
IP68 Rated AIS Base Station
,Inland Waterways AIS Base Station
Basic Properties
Trading Properties
Product Description
Designed for seamless integration with Dexonmarine’s AIS AtoN systems, the DX082FA forms a fully compatible solution that meets IALA and IMO standards. It supports multiple AIS message formats and includes options for 4G/5G connectivity, an Ethernet interface and solar power and battery operation. These features ensure easy scalability, centralised monitoring and real-time data flow for inland and offshore navigation safety systems.
Core advantages
- Fully compatible with Dexonmarine AIS AtoN systems, offering seamless integration and zero configuration friction.
- Supports multiple AIS message formats(21, 6, 8, 14) and is customisable for IALA and IMO compliance.
- Optional 4G/5G, Ethernet, solar power and battery modules allow for flexible deployment.
- IP68-rated, waterproof housing is made of corrosion-resistant FRP and is built to withstand harsh marine conditions.
- Enables real-time data flow and centralised monitoring for inland and offshore navigation safety.
- Ideal for ports, river channels and offshore platforms and is engineered for scalable maritime networks.
Technical specification
Category |
Specification |
Details |
|---|---|---|
|
Main features
|
Power Supply Range | AC 220V or DC 8~32V |
| Operating Frequency | 161.975MHz, 162.025MHz | |
| Frequency Error | ±0.3kHz | |
| Channel Bandwidth | 25KHz | |
| Receiving Sensitivity | ≤-107dBm | |
| Transmit Power | Default ≤6W, ≤12.5W(adjustible) | |
| Average Power Consumption | ≤1W(continuous operation) | |
| Interface Types | RS232, RS485, RJ45 | |
| Modulation Rate | 9600bps | |
| Data Format | NMEA 0183 | |
| Message Format | VDM | |
| Main/Backup Mode | Supported | |
| Operating Temperature | -30°C to +60°C | |
| Virtual Beacons | Supports up to 8 | |
| Weight | ≤8kg | |
| Local Storage | Expandable, supports up to 64GB |
Application
FAQ
1, Is it compatible with Dexonmarine AIS AtoN systems?
Yes. Seamless plug-and-play integration — no extra setup needed.
2, What AIS messages are supported?
Preloaded with messages 21, 6, 8, and 14; IALA/IMO-ready.
3, What deployment options are available?
Supports 4G/5G, Ethernet, solar, and battery for flexible use.
4, Is the device waterproof and corrosion-resistant?
Yes. IP68-rated FRP housing — built for extreme marine conditions.
5, Can it support real-time remote monitoring?
Absolutely. Enables centralised data flow for inland and offshore safety.
6, What’s the weight and shipping info?
≤8 kg unit. Ships within 3–10 days worldwide.
